Process exchanges clients

POST API: Vehicle Declaration

Description

This API allows you to execute an incoming flow for a specific client and a given translator. The accountId and translatorCode parameters are dynamic and must be provided in the URL.

URL

Full URL

https://api.dev.e4cars.io/api/v1/4pl/{accountId}/incoming-flows/vehicle/{translatorCode}?token={TOKEN}&dry_run=true

Full URL

https://api.dev.e4cars.io/api/v1/4pl/incoming-flows/vehicle/STD_IN_VEHICLE_ACCOUNT?token=18498cae876943a9aa2c72971645b75xxxx ...

METHOD

  • /POST

PATH parameters

  • accountId (string, required): unique identifier of the E4Cars client account.
  • translatorCode (string, required): code of the translator executing the incoming flow. The default standard translator is STD_IN_VEHICLE_ACCOUNT.

QUERY parameters

  • token (string, required): API key for authentication for the call. (see authentication section)
  • dry_run (string, optional, default=false): Allows you to run the translator for testing. Only the translation will be launched, the result will not be processed.
    • true: Only translation will run, no processing
    • false: Translation and processing of the translated flow will run.

REQUEST parameters

  • body (JSON Object, required): It contains a JSON object that will be transformed into the IncomingVehiclePivot structure, E4Cars' internal format.

    The object in body can also be an ad hoc object corresponding to the caller's or an existing API's needs.

    In this case, you should contact the E4Cars integration teams (integration@e4cars.com) so they can create an ad hoc translator to transform the body into IncomingVehiclePivot.

Standard flow translator case: translatorCode=STD_IN_VEHICLE_ACCOUNT

If you decide to use the standard flow translator (STD_IN_VEHICLE_ACCOUNT), you must adhere to the standard incoming manifest schema IncomingVehiclePivot below.

IncomingVehiclePivot schema
IncomingVehiclePivot.ts
export interface IncomingVehiclePivot {
    kind: string;
    issuing_date: string;
    issuer: {
        origin_software: string
    };
    vehicle_account: {
        vin : string;
        license_plate? : string
        customer_references : CustomerReference[]
        incoming_vehicle: {
            make : string;
            model : string;
            shape : string;
            color : string;
            engine : string;
            gearbox : string;
            energy_type : string;
            seats : number;
            description : string;
            features: string;
            vehicle_attributes : {
                length : string;
                width : string;
                height : string;
                weight : string;
                first_registration : string;
                mileage : {
                    value : string
                }
            }
        };
        incoming_seller: MemberRole;
        incoming_buyer:MemberRole;
        origin: {
            incoming_member_role: MemberRole
        };
        destination: {
            incoming_member_role: MemberRole
        };
        logistics_status: string;
        group : {
            code : string
        }
    };
    account : {
        code : string
    }
}

export interface CustomerReference {
    key: string;
    value: string;
}

export interface MemberRole {
    name: string;
    check_private: string;
    place_name: string;
    zip: string;
    city: string;
    country_code: string;
    platform: {
        code: string
    };
    contact: {
        name: string;
        phone: string;
        email: string
    };
    instructions: string
}
add features attibute
vehicle_account: {
        ...
    incoming_vehicle: {
        make : string;
        model : string;
        shape : string;
        color : string;
        engine : string;
        gearbox : string;
        energy_type : string;
        seats : number;
        description : string;
+       features: string;
        vehicle_attributes : {
            length : string;
            width : string;
            height : string;
            weight : string;
            first_registration : string;
            mileage : {
                value : string
            }
        }
    };
        ...
rename crm_dms_status in vehicle_account
    incoming_seller: MemberRole;
    incoming_buyer: MemberRole;
    origin: {
        incoming_member_role: MemberRole
    };
    destination: {
        incoming_member_role: MemberRole
    };
-   crm_dms_status: string;
+   logistics_status: string;
added external references
vehicle_account: {
-   customer_identification: string;
    vin : string;
    license_plate? : string
+   customer_references : CustomerReference[]
    incoming_vehicle: {
        ...
rename pickup and delivery in vehicle_account
    incoming_seller: MemberRole;
    incoming_buyer: MemberRole;
-   pickup : {
+   origin: {
        incoming_member_role: MemberRole
    };
-   delivery : {
+   destination: {
        incoming_member_role: MemberRole
    };
-   customer_crm_dms_status: string;
+   crm_dms_status: string;
Example of IncomingVehiclePivot Body
JSON
{
    "kind": "vehicle_declaration",
    "issuing_date": "2024-10-17T14:01:38",
    "issuer": {
        "origin_software": "DMS_CUST1"
    },
    "vehicle_account": {
        "vin" : "NMN291NZXHRZ91MSK",
        "license_plate" : "FU-80-EH",
        "customer_references" : [
            {
                "key" : "customer_identification",
                "value" : "ref-cust-vin-NMN291NZXHRZ91MSK"
            },
            {
                "key" : "order",
                "value" : "KJ948-EE409"
            }
        ],
        "incoming_vehicle": {
            "make" : "Peugeot",
            "model" : "E-3008",
            "shape" : "CUV",
            "color" : "Pourpre Sanglant",
            "engine" : "80ch",
            "gearbox" : "AUTOMATIQUE",
            "energy_type" : "ELECTRIQUE",
            "seats" : "5",
            "description" : "E-3008",
            "vehicle_attributes" : {
                "length" : "2500",
                "width" : "2000",
                "height" : "1800",
                "weight" : "1250",
                "first_registration" : "2023-07-14",
                "mileage" : {
                    "value" : "2000"
                }
            }
        },
        "incoming_seller": {
            "check_private": false,
            "name": "RENAULT BOULOGNE - RRG",
            "place_name": "577 Av. du Général Leclerc, 92100 Boulogne-Billancourt",
            "zip": "92100",
            "city": "Boulogne-Billancourt",
            "country_code": "FR",
            "platform": {
                "code": "RRG1"
            },
            "contact": {
                "name": "Michel Durand",
                "phone": "O1 46 23 43 22",
                "email": "michel.durand@rrg.com"
            },
            "instructions": "Driver need token at pickup : 239-MM345-UH1"
        },
        "incoming_buyer":{
            "check_private": "true",
            "name": "Monique Marchal",
            "place_name": "27 rue du puit, 75019 Paris",
            "zip": "75019",
            "city": "Paris",
            "country_code": "FR",
            "contact": {
                "name": "Monique Marchal",
                "phone": "07 07 07 07 07",
                "email": "monique@marchal.fr"
            },
            "instructions": "Pas aux heures de repas"
        },
        "origin": {
            "incoming_member_role": {
                "check_private": "false",
                "name": "RENAULT BOULOGNE - RRG",
                "place_name": "577 Av. du Général Leclerc, 92100 Boulogne-Billancourt",
                "zip": "92100",
                "city": "Boulogne-Billancourt",
                "country_code": "FR",
                "platform": {
                    "code": "RRG1"
                },
                "contact": {
                    "name": "Michel Durand",
                    "phone": "O1 46 23 43 22",
                    "email": "michel.durand@rrg.com"
                },
                "instructions": "Driver need token at pickup : 239-MM345-UH1"
            }
        },
        "destination": {
            "incoming_member_role": {
                "check_private": "true",
                "name": "Monique Marchal",
                "place_name": "27 rue du puit, 75019 Paris",
                "zip": "75019",
                "city": "Paris",
                "country_code": "FR",
                "contact": {
                    "name": "Monique Marchal",
                    "phone": "07 07 07 07 07",
                    "email": "monique@marchal.fr"
                },
                "instructions": "Pas aux heures de repas"
            }
        },
        "crm_dms_status" : "sold",
        "group" : {
            "code" : "FLT"
        }
    },
    "account" : {
        "code" : "NMN"
    }
}

E4Cars Custom Incoming Flow Translator

The object in body can be an ad hoc object corresponding to the needs of an existing API.

In this case, as with E4Cars' outgoing flows, you should contact the E4Cars integration teams (integration@e4cars.com) to send them the body you wish to send for creating a vehicle.

They will create a custom translator that will be used when transmitting vehicle creation orders, converting an IncomingVehiclePivot from the ad hoc information.


Example of URL

Full URL

https://api.dev.e4cars.io/api/v1/4pl/incoming-flows/vehicle/STD_IN_VEHICLE_ACCOUNT?token=18498cae876943a9aa2c72971645b75xxxx ...


NAME NATURE TYPE PLACE VALUE
ACCOUNT_ID CONSTANT string Path param Default value
ID_TRANSLATOR CONSTANT String Path param Default value
TOKEN CONSTANT string Query param Default value
dry_run CONSTANT string Query param Default false
"vehicle_account.group.code" CONSTANT JSON object Body Default value
"kind" CONSTANT JSON object Body "vehicle_declaration"
"account.code" CONSTANT JSON object Body ACCOUNT_ID
NAME NATURE TYPE PLACE VALUE
"vehicle_account.incoming_vehicle.shape" VARIABLE String Body Dynamic
Below is the list of accepted values for vehicle.shape:
Name Value
CABRIOLET CABRIOLET
COUPE COUPE
CUV CUV
HATCHBACK HATCHBACK
MICRO MICRO
MINIVAN MINIVAN
PICKUP PICKUP
ROADSTER ROADSTER
SEDAN SEDAN
SUPERCAR SUPERCAR
SUV SUV

Date value

All date (IN or OUT) are Locale

Below is the list of all accepted date formats:

  • YYYY-MM-DDTHH24:MI:SS
  • YYYY-MM-DDTHH24:MI:SSZ
  • YYYY-MM-DDTHH24:MI
  • YYYY-MM-DDTHH24:MI:SS.ms
  • YYYY-MM-DDTHH24:MI:SS.msZ

The POST request requires a body in JSON format containing the necessary information to execute the incoming flow. Here is an example of the body structure:

Example of JSON Body
JSON
{
    "kind": "vehicle_declaration",
    "issuing_date": "2024-10-17T14:01:38",
    "issuer": {
        "origin_software": "DMS_CUST1"
    },
    "vehicle_account": {
        "vin" : "NMN291NZXHRZ91MSK",
        "license_plate" : "FU-80-EH",
        "customer_references" : [
            {
                "key" : "customer_identification",
                "value" : "ref-cust-vin-NMN291NZXHRZ91MSK"
            },
            {
                "key" : "order",
                "value" : "KJ948-EE409"
            }
        ],
        "incoming_vehicle": {
            "make" : "Peugeot",
            "model" : "E-3008",
            "shape" : "CUV",
            "color" : "Pourpre Sanglant",
            "engine" : "80ch",
            "gearbox" : "AUTOMATIQUE",
            "energy_type" : "ELECTRIQUE",
            "seats" : "5",
            "description" : "E-3008",
            "vehicle_attributes" : {
                "length" : "2500",
                "width" : "2000",
                "height" : "1800",
                "weight" : "1250",
                "first_registration" : "2023-07-14",
                "mileage" : {
                    "value" : "2000"
                }
            }
        },
        "incoming_seller": {
            "check_private": false,
            "name": "RENAULT BOULOGNE - RRG",
            "place_name": "577 Av. du Général Leclerc, 92100 Boulogne-Billancourt",
            "zip": "92100",
            "city": "Boulogne-Billancourt",
            "country_code": "FR",
            "platform": {
                "code": "RRG1"
            },
            "contact": {
                "name": "Michel Durand",
                "phone": "O1 46 23 43 22",
                "email": "michel.durand@rrg.com"
            },
            "instructions": "Driver need token at pickup : 239-MM345-UH1"
        },
        "incoming_buyer":{
            "check_private": "true",
            "name": "Monique Marchal",
            "place_name": "27 rue du puit, 75019 Paris",
            "zip": "75019",
            "city": "Paris",
            "country_code": "FR",
            "contact": {
                "name": "Monique Marchal",
                "phone": "07 07 07 07 07",
                "email": "monique@marchal.fr"
            },
            "instructions": "Pas aux heures de repas"
        },
        "origin": {
            "incoming_member_role": {
                "check_private": "false",
                "name": "RENAULT BOULOGNE - RRG",
                "place_name": "577 Av. du Général Leclerc, 92100 Boulogne-Billancourt",
                "zip": "92100",
                "city": "Boulogne-Billancourt",
                "country_code": "FR",
                "platform": {
                    "code": "RRG1"
                },
                "contact": {
                    "name": "Michel Durand",
                    "phone": "O1 46 23 43 22",
                    "email": "michel.durand@rrg.com"
                },
                "instructions": "Driver need token at pickup : 239-MM345-UH1"
            }
        },
        "destination": {
            "incoming_member_role": {
                "check_private": "true",
                "name": "Monique Marchal",
                "place_name": "27 rue du puit, 75019 Paris",
                "zip": "75019",
                "city": "Paris",
                "country_code": "FR",
                "contact": {
                    "name": "Monique Marchal",
                    "phone": "07 07 07 07 07",
                    "email": "monique@marchal.fr"
                },
                "instructions": "Pas aux heures de repas"
            }
        },
        "crm_dms_status" : "sold",
        "group" : {
            "code" : "FLT"
        }
    },
    "account" : {
        "code" : "NMN"
    }
}
Code Description Example Response
200 Success, the flow was executed correctly. { "status": "success", "message": "Incoming flow executed successfully." }
401 Unauthorized, missing or invalid authentication. { "status": "error", "message": "Unauthorized. Please authenticate." }
403 Forbidden, insufficient permissions. { "status": "error", "message": "Forbidden. You do not have the necessary permissions to execute this flow." }
400 Bad request, invalid body or parameters. { "status": "error", "message": "Invalid request. Ensure all parameters are correctly provided." }

POST API: Receive vehicle on yard

Description

This API allows you to execute an incoming flow for a specific client and a given translator . The accountId and translatorCode (STD_IN_ENTER_VEHICLE_YARD) parameters are dynamic and must be provided in the URL.

URL

Full URL

https://api.dev.e4cars.io/api/v1/4pl/{accountId}/incoming-flows/orders/{translatorCode}?token={TOKEN}&dry_run=true

Full URL

https://api.dev.e4cars.io/api/v1/4pl/incoming-flows/orders/STD_IN_ENTER_VEHICLE_YARD?token=18498cae876943a9aa2c72971645b75xxxx ...

METHOD

  • /POST

PATH parameters

  • accountId (string, required): unique identifier of the E4Cars client account.
  • translatorCode (string, required): code of the translator executing the incoming flow. The default standard translator is STD_IN_ENTER_VEHICLE_YARD.

QUERY parameters

  • token (string, required): API key for authentication for the call. (see authentication section)
  • dry_run (string, optional, default=false): Allows you to run the translator for testing. Only the translation will be launched, the result will not be processed.
    • true: Only translation will run, no processing
    • false: Translation and processing of the translated flow will run.

REQUEST parameters

  • body (JSON Object, required): It contains a JSON object that will be transformed into the IncomingOrderPivot structure, E4Cars' internal format.

    The object in body can also be an ad hoc object corresponding to the caller's or an existing API's needs.

    In this case, you should contact the E4Cars integration teams (integration@e4cars.com) so they can create an ad hoc translator to transform the body into IncomingOrderPivot.

Standard flow translator case: translatorCode=STD_IN_ENTER_VEHICLE_YARD

If you decide to use the standard flow translator (STD_IN_ENTER_VEHICLE_YARD), you must adhere to the standard incoming manifest schema IncomingOrderPivot below.

IncomingOrderPivot schema
IncomingOrderPivot.ts
export interface IncomingOrderPivot {
  customer_incoming_order_no?: string;
  kind: string;
  issuing_date: string;
  issuer: {
    origin_software: string;
  };
  vehicle_account: {
    vin: string;
    license_plate?: string;
    dms_reference?: string;
    incoming_vehicle?: {
        make: string;
        model: string;
        shape?: string;
        color?: string;
        engine?: string;
        gearbox?: string;
        energy_type?: string;
        seats?: string;
        description?: string;
        vehicle_attributes?: {
            length?: string;
            width?: string;
            height?: string;
            weight?: string;
            mileage?: {
                value: string;
              };
            first_registration?: string;
          };
      };
    incoming_seller?: {
        name?: string;
        zip: string;
        city: string;
        country_code: string;
        place_name?: string;
        display_place_name?: string;
        timezone?: string;
        geo_point?: {
            type: string;
            coordinates: [number, number];
          };
        check_private: string;
        instructions?: string;
        contact?: {
            name?: string;
            email?: string;
            phone?: string;
            language?: string;
          };
      };
    incoming_buyer?: {
        name?: string;
        zip: string;
        city: string;
        country_code: string;
        place_name?: string;
        display_place_name?: string;
        timezone?: string;
        geo_point?: {
            type: string;
            coordinates: [number, number];
          };
        check_private: string;
        instructions?: string;
        contact?: {
            name?: string;
            email?: string;
            phone?: string;
            language?: string;
          };
      };
    pickup?: {
        incoming_member_role?: {
            name?: string;
            zip: string;
            city: string;
            country_code: string;
            place_name?: string;
            display_place_name?: string;
            timezone?: string;
            geo_point?: {
                type: string;
                coordinates: [number, number];
              };
            check_private: string;
            instructions?: string;
            contact?: {
                name?: string;
                email?: string;
                phone?: string;
                language?: string;
              };
          };
      };
    delivery?: {
        incoming_member_role?: {
            name?: string;
            zip: string;
            city: string;
            country_code: string;
            place_name?: string;
            display_place_name?: string;
            timezone?: string;
            geo_point?: {
                type: string;
                coordinates: [number, number];
              };
            check_private: string;
            instructions?: string;
            contact?: {
                name?: string;
                email?: string;
                phone?: string;
                language?: string;
              };
          };
      };
    crm_dms_status?: string;
    group?: {
      code: string;
    };
  };
  account?: {
    code: string;
  };
}
Example of IncomingOrderPivot Body
JSON
{
  "customer_incoming_order_no": "VOL-2345-RTG-3089487",
  "kind": "vehicle_enter_platform",
  "issuing_date": "2025-03-19T13:01:02",
  "issuer": {
    "origin_software": "VOL-DMS"
  },
  "account": {
    "code": "VOL"
  },
  "allocation": {
    "pickup": {
      "incoming_member_role": {
        "name": "CEVA ETUPES",
        "zip": "25460",
        "city": "Étupes",
        "country_code": "FR",
        "place_name": "1375 Avenue Oehmichen, 25460 Étupes, France",
        "contact": {
          "name": "Nicolas Melisson",
          "email": "ni.co@las.mel",
          "phone": "+33 6 01 02 03 04",
          "language": "fr"
        },
        "platform": {
          "code": "CEV_ETUPES"
        },
        "check_private": false
      },
      "target_date": {
        "date": "2025-03-26T23:00:00",
        "utc_date": "2025-03-26T22:00:00"
      }
    },
    "delivery": {
      "incoming_member_role": {
        "name": "CEVA ETUPES",
        "zip": "25460",
        "city": "Étupes",
        "country_code": "FR",
        "place_name": "1375 Avenue Oehmichen, 25460 Étupes, France",
        "timezone": "Europe/Paris",
        "platform": {
          "code": "CEV_ETUPES"
        },
        "check_private": false
      },
      "target_date": {
        "date": "2025-03-27T00:00:00",
        "utc_date": "2025-03-26T23:00:00"
      }
    },
    "vehicles": [
      {
        "vin": "NMN085J9M95FUBPCN",
        "license_plate": "DCH-56-NGL",
        "customer_references": [
          {
            "key": "dms_reference",
            "value": "DMS12J68JU1"
          },
          {
            "key": "key1",
            "value": "value1"
          },
          {
            "key": "key2",
            "value": "value2"
          }
        ],
        "incoming_vehicle": {
          "make": "FERRARI",
          "model": "F8 SPYDER",
          "shape": "COUPE"
        },
        "incoming_seller": {
          "name": "AUTO1 France",
          "zip": "92320",
          "city": "Châtillon",
          "country_code": "FR",
          "timezone": "Europe/Paris",
          "contact": {
            "name": "John Doe",
            "email": "auto1.testnmn@e4cars.com",
            "phone": "+330101010101",
            "language": "fr"
          }
        },
        "incoming_buyer": {
          "name": "Renault - Cordes-sur-Ciel",
          "zip": "81000",
          "city": "Albi",
          "country_code": "FR",
          "place_name": "81000 Albi, France",
          "timezone": "Europe/Paris"
        },
        "origin": {
          "incoming_member_role": {
            "zip": "77171",
            "city": "Sourdun",
            "country_code": "FR",
            "place_name": "77171 Sourdun, France",
            "timezone": "Europe/Paris",
            "contact": {
              "name": "John Doe",
              "email": "origin.testnmn@e4cars.com",
              "phone": "+330101010101",
              "language": "fr"
            }
          }
        },
        "destination": {
          "incoming_member_role": {
            "name": "Debard Automobiles Albi",
            "zip": "81000",
            "city": "Albi",
            "country_code": "FR",
            "place_name": "81000 Albi, France",
            "timezone": "Europe/Paris",
            "contact": {
              "name": "John Doe",
              "email": "debard.testnmn@e4cars.com",
              "phone": "+330101010101",
              "language": "fr"
            }
          }
        },
        "logistics_status": "ordered",
        "group": {
          "code": "FLT"
        }
      }
    ]
  }
}

E4Cars Custom Incoming Flow Translator

The object in body can be an ad hoc object corresponding to the needs of an existing API.

In this case, as with E4Cars' outgoing flows, you should contact the E4Cars integration teams (integration@e4cars.com) to send them the body you wish to send for creating a vehicle.

They will create a custom translator that will be used when transmitting vehicle creation orders, converting an IncomingOrderPivot from the ad hoc information.


Example of URL

Full URL

https://api.dev.e4cars.io/api/v1/4pl/incoming-flows/orders/STD_IN_ENTER_VEHICLE_YARD?token=18498cae876943a9aa2c72971645b75xxxx ...


NAME NATURE TYPE PLACE VALUE
ACCOUNT_ID CONSTANT string Path param Default value
ID_TRANSLATOR CONSTANT String Path param Default value
TOKEN CONSTANT string Query param Default value
dry_run CONSTANT string Query param Default false
"vehicle_account.group.code" CONSTANT JSON object Body Default value
"kind" CONSTANT JSON object Body "vehicle_enter_platform"
"account.code" CONSTANT JSON object Body ACCOUNT_ID
NAME NATURE TYPE PLACE VALUE
"vehicle_account.incoming_vehicle.shape" VARIABLE String Body Dynamic
Below is the list of accepted values for vehicle.shape:
Name Value
CABRIOLET CABRIOLET
COUPE COUPE
CUV CUV
HATCHBACK HATCHBACK
MICRO MICRO
MINIVAN MINIVAN
PICKUP PICKUP
ROADSTER ROADSTER
SEDAN SEDAN
SUPERCAR SUPERCAR
SUV SUV

Date value

All date (IN or OUT) are UTC

Below is the list of all accepted date formats:

  • YYYY-MM-DDTHH24:MI:SS
  • YYYY-MM-DDTHH24:MI:SSZ
  • YYYY-MM-DDTHH24:MI
  • YYYY-MM-DDTHH24:MI:SS.ms
  • YYYY-MM-DDTHH24:MI:SS.msZ

The POST request requires a body in JSON format containing the necessary information to execute the incoming flow. Here is an example of the body structure:

Example of JSON Body
JSON
{
  "customer_incoming_order_no": "VOL-2345-RTG-3089487",
  "kind": "vehicle_enter_platform",
  "issuing_date": "2025-03-19T13:01:02",
  "issuer": {
    "origin_software": "VOL-DMS"
  },
  "account": {
    "code": "VOL"
  },
  "allocation": {
    "pickup": {
      "incoming_member_role": {
        "name": "CEVA ETUPES",
        "zip": "25460",
        "city": "Étupes",
        "country_code": "FR",
        "place_name": "1375 Avenue Oehmichen, 25460 Étupes, France",
        "contact": {
          "name": "Nicolas Melisson",
          "email": "ni.co@las.mel",
          "phone": "+33 6 01 02 03 04",
          "language": "fr"
        },
        "platform": {
          "code": "CEV_ETUPES"
        },
        "check_private": false
      },
      "target_date": {
        "date": "2025-03-26T23:00:00",
        "utc_date": "2025-03-26T22:00:00"
      }
    },
    "delivery": {
      "incoming_member_role": {
        "name": "CEVA ETUPES",
        "zip": "25460",
        "city": "Étupes",
        "country_code": "FR",
        "place_name": "1375 Avenue Oehmichen, 25460 Étupes, France",
        "timezone": "Europe/Paris",
        "platform": {
          "code": "CEV_ETUPES"
        },
        "check_private": false
      },
      "target_date": {
        "date": "2025-03-27T00:00:00",
        "utc_date": "2025-03-26T23:00:00"
      }
    },
    "vehicles": [
      {
        "vin": "NMN085J9M95FUBPCN",
        "license_plate": "DCH-56-NGL",
        "customer_references": [
          {
            "key": "dms_reference",
            "value": "DMS12J68JU1"
          },
          {
            "key": "key1",
            "value": "value1"
          },
          {
            "key": "key2",
            "value": "value2"
          }
        ],
        "incoming_vehicle": {
          "make": "FERRARI",
          "model": "F8 SPYDER",
          "shape": "COUPE"
        },
        "incoming_seller": {
          "name": "AUTO1 France",
          "zip": "92320",
          "city": "Châtillon",
          "country_code": "FR",
          "timezone": "Europe/Paris",
          "contact": {
            "name": "John Doe",
            "email": "auto1.testnmn@e4cars.com",
            "phone": "+330101010101",
            "language": "fr"
          }
        },
        "incoming_buyer": {
          "name": "Renault - Cordes-sur-Ciel",
          "zip": "81000",
          "city": "Albi",
          "country_code": "FR",
          "place_name": "81000 Albi, France",
          "timezone": "Europe/Paris"
        },
        "origin": {
          "incoming_member_role": {
            "zip": "77171",
            "city": "Sourdun",
            "country_code": "FR",
            "place_name": "77171 Sourdun, France",
            "timezone": "Europe/Paris",
            "contact": {
              "name": "John Doe",
              "email": "origin.testnmn@e4cars.com",
              "phone": "+330101010101",
              "language": "fr"
            }
          }
        },
        "destination": {
          "incoming_member_role": {
            "name": "Debard Automobiles Albi",
            "zip": "81000",
            "city": "Albi",
            "country_code": "FR",
            "place_name": "81000 Albi, France",
            "timezone": "Europe/Paris",
            "contact": {
              "name": "John Doe",
              "email": "debard.testnmn@e4cars.com",
              "phone": "+330101010101",
              "language": "fr"
            }
          }
        },
        "logistics_status": "ordered",
        "group": {
          "code": "FLT"
        }
      }
    ]
  }
}
Code Description Example Response
200 Success, the flow was executed correctly. { "status": "success", "message": "Incoming flow executed successfully." }
401 Unauthorized, missing or invalid authentication. { "status": "error", "message": "Unauthorized. Please authenticate." }
403 Forbidden, insufficient permissions. { "status": "error", "message": "Forbidden. You do not have the necessary permissions to execute this flow." }
400 Bad request, invalid body or parameters. { "status": "error", "message": "Invalid request. Ensure all parameters are correctly provided." }

Work in progress

Work in progress
